| BASIC
INFO |
| Model No. |
UTAB
T11 PRO MAX |
| Dimension |
275*178*18mm |
| Net Weight |
920g
(include battery) |
| Housing Material |
ABS+PC |
| Operation system |
Android
13 (GMS Passed) |
| Languages |
Multi-languages |
| HARDWARE |
| Screen |
10.1
inch FHD IPS capacitive touch screen, 1920*1200px, 450nits, support stylus.
(1000 nits optional） |
| Processor |
Mediatek
MT6789 Helio G99 Octa Core, 2.2GHz; GPU:Mali-G57 MC2, 2133MHz |
| Network Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100MHz; TD-SCDMA: B34/B39; CDMA 2000: BC0 |
| 4G: FDD-LTE:
B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28/B66; TDD-LTE: B34/B38/B39/B40/B41 |
| RAM |
8GB
RAM |
| ROM |
128GB
or 256GB ROM, support TF card up to 512GB maximally |
| Camera |
Double
cameras: 5MP front; 13MP back camera
with LED flashlight |
| Main Battery |
Removable
3.8V/12000mAh li-ion polymer battery |
| Backup Battery |
Built-in
2100mAh li-ion polymer battery |
| Sensors |
Light
sensor, magnetic sensor, gravity sensor, acceleration sensor, barometer |
| Speaker |
1.5
watt stereo speaker*2 |
| Keys |
Volume
+/-, Power key, P key, F key, H key |
| NETWORK
& CONNECTIVITY |
| WIFI |
IEEE
802.11a/b/g/n/ac, support 2.4GHz/5GHz dual band wifi, support wireless AP |
| BT |
V5.0 |
| NFC |
Support,
13.56MHz |
| GNSS |
Support
GPS/A-GPS/Beidou/GLONASS/Galileo |
| I/O
INTERFACES |
| USB Type-A |
*1 |
| Pogo Pin |
*2
( Bottom 8 PIN for 1USB, 1 RS232, 1 UART;
Back 16 PIN for 1USB, 1 RS232, 1 UART，3.3V, 5V OUT ) |
| USB Type-C |
*1 |
| RJ45 Port |
*1 |
| RS232 |
*1 |
| 3.5mm DC-in |
*1 |
| 3.5mm Audio Jack |
*1 |
| RELIABILITY |
| Waterproof |
IP67
waterproof/MIL-STD-810G |
| Drop-proof |
1.2m
drop test |
| Temperature range |
Operating:
'20℃-60℃; Storage:'25℃~80℃ |
| OPTIONAL
FUNCTIONS |
| Fingerprint Unlock |
Optional
(LD-8800-M) |
| 2D Barcode Scanner |
Optional
(Honeywell N3680) |
| UHF RFID |
Optional
(1~10 meters) |
| High-precision positioning |
Optional |
| ACCESSORIES |
| Wall Charger (5V/3A) |
*1,
(4-in-1) |
| Mini Screwer |
*1 |
| Hand Strap |
*1 |
| Hand String |
*1 |
| User Manual |
*1 |
| Car Holder |
Optional |
| Car Docking |
Optional |
| Charging Dock |
Optional |
| Safety Box |
Optional |
