| BASIC INFO |
| Model No. |
WinPad
W88 |
| Operating System |
Windows 10 and Ubuntu |
| Dimension |
236.7*155.7*20mm |
| Weight |
910g |
| Color |
Black |
| Language |
Multi-language |
| HARDWARE |
| Display |
8
inch tempered glass IPS capacitive screen, 1920*1200px, 550cd/m2 |
| Processor |
Intel
JASPER LAKE N5100 quad core, 2.8GHz; GPU: Intel HD Graphics Gen 11 LP |
| RAM |
4GB
LPDDR3, 8GB optional |
| ROM |
64GB
emmc, 128GB optional, support Micro SD card up to 512GB maximally |
| Camera |
Double
cameras: Rear 8MP AF with flashlight, Front 5MP |
| Battery |
Removable
7.6V/5000mAh Li-Polymer battery |
| Real Time Clock |
Built-in
rechargeable 3 V/1mAh lithium ion battery |
| G-sensor |
Support |
| Speaker |
Embedded
8Ω/0.8W speaker*2 |
| LED Indicator |
RGB |
| Mic |
Single
MIC |
| Key |
2D
code scanning key*1, Power key*1, Volume key+/-*1, Home key*1 |
| NETWORK & CONNECTIVITY |
| Bands |
2G
GSM900/1800MHz |
| 3G WCDMA850/900/2100MHz |
| 4G FDD-LTE B1/B3/B5/B7/B8/B20, TDD-LTE: B40 |
| WiFi |
IEEE
802.11a/b/g/n/ac, support 2.4G/5.8GHz dual band WiFi |
| BT |
V4.2(BLE),
transmission distance: up to 10 meters |
| GNSS |
Support
GPS/Beidou/GLONASS |
| I/O INTERFACES |
| TF card slot |
*1 |
| Nano SIM card slot |
*1 |
| USB Type-A 3.0 |
*1 |
| USB Type-C 2.0 |
*1 |
| 3.5mm earphone jack |
*1 |
| Mini HD-MI 1.4a |
*1 |
| 12pin Pogo Pin |
*1 |
| OPTIONAL FEATURES |
| 2D barcode scanning |
Optional
(Honeywell N4680) |
| NFC |
Optional
(Support 14443A/14443B/15693/18092/mifare protocol) |
| RELIABILITY |
| Waterproof |
IP65 |
| Drop-proof |
MIL-STD-810G
1.22m drop |
| Electrostatic discharge |
±
8KV contact discharge, ± 10kV air discharge |
| Temperature range |
Operating:
'-20 °C to 60 °C, storage: '-30 °C to 70 °C |
| Humidity range |
95%
Non-Condensing |
| ACCESSORIES |
| Type-C USB data Cable |
*1 |
| Hand-strap |
*1 |
| Power Adaptor (19V/3.42A) |
*1 |
