| BASIC INFO |
| Model No. |
UTAB
R801 |
| Operating system |
Android
11 |
| Dimension |
246*148*17mm |
| Weight |
743g
(include battery) |
| Material |
Plastic |
| Color |
Black |
| Languages |
Multi-language |
| HARDWARE |
| Screen |
8.0
inch Corning Gorilla capacitive touch screen, 1280*800px, 550cd/㎡ (FHD
optional) |
| Processor |
MT6771T
Helio P60 octa core 2.0GHz (4*A73+4*A53);
GPU: Mali-G72 MP3 |
| RAM |
4GB
RAM (6GB optional) |
| ROM |
64GB
ROM (128GB optional), support TF card up to 256GB maximally |
| Camera |
Double
cameras: 5.0MP front, 13MP AF rear camera with flashlight |
| Battery |
Built-in
3.8V/10000mAh li-polymer battery |
| Sensors |
Gravity
sensor, light sensor, proximity sensor, gyroscope, magnetic field sensor |
| Speaker |
1.5W/8Ω
waterproof speaker*2 |
| Buttons |
Power,
Volume +/-, PTT, F1, F2, F3, F4 |
| NETWORK & CONNECTIVITY |
| Network Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100MHz; TD-SCDMA:
B34/B39; CDMA2000: BC0/BC1 |
| 4G: FDD-LTE
B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28, TDD-LTE: B34/B38/B39/B40/B41 |
| Wi-Fi |
IEEE
802.11a/b/g/n/ac, Support
2.4GHz/5.8GHz dual-band Wi-Fi |
| BT |
V4.2
(BLE) class1, transfer distance: 10m |
| NFC |
NXP,
13.56MHz Support
14443A/14443B/15693/18092/mifare protocol |
| GNSS |
Support
GPS/A-GPS/Beidou/GLONASS/Galileo |
| I/O INTERFACES |
| Micro SIM card slot |
*1 |
| TF Card Slot |
*1 |
| Mini HD-MI port |
*1 |
| 3.5mm Audio Jack |
*1 |
| USB Type-A 3.0 |
*1 |
| USB Type-C 2.0 |
*1 |
| 5V/3A DC-IN |
*1 |
| Pogo Pin |
*1 |
| OPTIONAL FUNCTIONS |
| Fingerprint Module |
Optional |
| ID Card Identification |
Optional |
| 1D/2D Scanning Module |
Optional |
| High-Precision
Positioning |
Optional |
| Living
Binocular |
Optional |
| Iris
Recognition |
Optional |
| Infrared
Thermal Imaging |
Optional |
| LORA |
Optional |
| RFID |
Optional |
| RELIABILITY |
| Waterproof |
IP68 |
| Drop-proof |
1.2m
drop |
| Temperature range |
Operating:
-20℃~60℃, Storage: -40℃~70℃ |
| STANDARD ACCESSORIES |
| Power Adaptor (5V/3A) |
*1 |
| USB Cable |
*1 |
| Hand strap |
*1 |
| User Manual |
*1 |
